Nginx

Nginx

This section described how to use nginx (https://nginx.org/en/) as a web server, one of the two reverse-proxy options supported alongside Apache. The Platform’s server components can be made highly performant by using the lightweight Nginx as a reverse-proxy along with a WSGI server. Using nginx enabled the server to scale to a large number of users with ease.

To use Nginx, it needs to be installed in the system the daemon should be running with the appropriate site configurations setup.

Installation

The official installation instructions can be found at https://nginx.org/en/docs/install.html

The recommended method of installation is to use the package manager provided by the Operating System (apt-get, yum, etc.).

RedHat:

yum install nginx

Ubuntu:

apt install nginx

Configurations

Once installed, the nginx configuration needs to be created to proxy the web server components as described in https://nginx.org/en/docs/beginners_guide.html#proxy

Here is an example nginx configuration that sets up the Web Application Server and also routes the /jupyter endpoint to the Jupyter component:

server {
  listen 80;
  server_name localhost 0.0.0.0;

  client_max_body_size 100m;
  gzip on;
  gzip_vary on;
  gzip_min_length 10240;
  gzip_proxied expired no-cache no-store private auth;
  gzip_types text/plain text/css text/xml text/javascript application/x-javascript application/javascript application/xml application/json ;
  gzip_disable "MSIE [1-6]\.";

  location / {
    proxy_set_header   X-Real-IP        $remote_addr;
    proxy_set_header   X-Forwarded-For  $proxy_add_x_forwarded_for;
    proxy_set_header   X-Forwarded-Proto $scheme;
    proxy_set_header   Host             $http_host;

    proxy_pass http://localhost:5002;
    proxy_read_timeout 3600;
  }

  location /jupyter {
    proxy_set_header   X-Real-IP        $remote_addr;
    proxy_set_header   X-Forwarded-For  $proxy_add_x_forwarded_for;
    proxy_set_header   X-Forwarded-Proto $scheme;
    proxy_set_header   Host             $http_host;

    proxy_pass http://localhost:5003;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_read_timeout 86400;
  }
}

Note

If the nginx is not listening on port 80 - but listens on another port, the proxy_set_header for Host may have to be modified to proxy_set_header Host $http_host to ensure the correct host information is passed.

Note: Permission issues

In case of permission issues, ensure user permissions and SELinux is set up correctly.

Note: Large file uploads

If large files are expected to be uploaded, there are two settings that need to be modified
  1. add proxy_request_buffering off
  2. add client_max_body_size 0;
to server directive which expects large file size payload. This will disable nginx from buffering the large payload files and optimize disk space consumption.
